3RK1405-0BE00-0AA2 - AS-I SAFE, 22.5F, 2FE/2A, W/O AUX
by Siemens
Original price
$371.63
-
Original price
$371.63
Original price
$371.63
$371.63
-
$371.63
Current price
$371.63
SCREW TERMINAL AND TWO STANDARD OUTPUTS 2DO TWO SAFE INPUTS 2FDI ASISAFE MODULE S22,5F
| Item | Value |
|---|---|
| Country of Origin | DE |
| Depth | 91 mm |
| Width | 22.5 mm |
| Height | 101.6 mm |
| IO link master | false |
| System accessory | true |
| Radio standard GSM | false |
| Radio standard GPRS | false |
| Radio standard UMTS | false |
| Type of output voltage | DC |
| Number of digital outputs | 2 |
| Input current at signal 1 | 5 A |
| Rack-assembly possible | false |
| Rail mounting possible | false |
| SIL according to IEC 61508 | 3 |
| Type of digital output | Other |
| With optical interface | false |
| Front build in possible | false |
| Number of HW-interfaces USB | 0 |
| Degree of protection (IP) | IP20 |
| Radio standard Bluetooth | false |
| Number of HW-interfaces other | 0 |
| Number of interfaces PROFINET | 0 |
| Number of HW-interfaces RS-232 | 0 |
| Number of HW-interfaces RS-422 | 0 |
| Number of HW-interfaces RS-485 | 0 |
| Radio standard WLAN 802.11 | false |
| Supporting protocol for ASI | true |
| Supporting protocol for CAN | false |
| Supporting protocol for KNX | false |
| Supporting protocol for LON | false |
| Voltage type of supply voltage | DC |
| Digital outputs configurable | false |
| Number of HW-interfaces Wireless | 0 |
| Number of HW-interfaces parallel | 0 |
| Type of voltage (input voltage) | DC |
| Wall mounting/direct mounting | false |
| Number of HW-interfaces serial TTY | 0 |
| Supporting protocol for MODBUS | false |
| Supporting protocol for SERCOS | false |
| Supporting protocol for TCP/IP | false |
| Supporting protocol for SUCONET | false |
| Explosion safety category for gas | None |
| Supporting protocol for INTERBUS | false |
| Supporting protocol for PROFIBUS | false |
| Appendant operation agent (Ex ia) | false |
| Appendant operation agent (Ex ib) | false |
| Supporting protocol for DeviceNet | false |
| Supporting protocol for PROFIsafe | false |
| Supporting protocol for EtherNet/IP | false |
| Supporting protocol for PROFINET IO | false |
| Supporting protocol for SafetyBUS p | false |
| Supporting protocol for Data-Highway | false |
| Supporting protocol for PROFINET CBA | false |
| Type of electric connection | Screw connection |
| Number of HW-interfaces industrial Ethernet | 0 |
| Performance level acc. EN ISO 13849-1 | Level e |
| Supporting protocol for INTERBUS-Safety | false |
| Supporting protocol for DeviceNet Safety | false |
| Supporting protocol for other bus systems | false |
| Short-circuit protection, outputs available | true |
| Supporting protocol for Foundation Fieldbus | false |
| Supporting protocol for AS-Interface Safety at Work | true |
