3VA5245-6ED32-0AA0 - BRKR 3VA52 3P 45A 65KA FTFM NUT

3VA5245-6ED32-0AA0 - BRKR 3VA52 3P 45A 65KA FTFM NUT

by Siemens
$493.99 - $493.99
$493.99
$493.99 - $493.99
$493.99

MLFB Lo



Specifications
Item Value
Country of Origin CZ
Number of poles 3
Rated voltage 690 V
Motor drive optional true
Motor drive integrated false
Degree of protection (IP) IP40
Rated permanent current Iu 45 A
With switched-off indicator false
Overload release current setting 45 A
Type of control element Rocker lever
Integrated earth fault protection false
Complete device with protection unit true
With integrated under voltage release false
DIN rail (top hat rail) mounting optional false
Suitable for DIN rail (top hat rail) mounting false
Adjustment range undelayed short-circuit release 450 A
Number of auxiliary contacts as change-over contact 0
Number of auxiliary contacts as normally open contact 0
Number of auxiliary contacts as normally closed contact 0
Position of connection for main current circuit Front side
Device construction Built-in device fixed built-in technique
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz 70 kA

SIRIUS Circuit breaker S00 / S0
