5SJ4114-7HG42 - MCB 5SJ4 1P 277V 0.3A 10K C-TRIP
by Siemens
Original price
$45.35
-
Original price
$45.35
Original price
$45.35
$45.35
-
$45.35
Current price
$45.35
CIRCUIT BREAKER 10KA, 1POLE, C, 0.3A ACC. TO UL 489 - 277V
| Item | Value |
|---|---|
| Pollution degree | 3 |
| Country of Origin | DE |
| Rated current | 0.3 A |
| Rated voltage | 400 V |
| Voltage type | AC/DC |
| Built-in depth | 70 mm |
| Explosion-proof | false |
| Over voltage category | 3 |
| Release characteristic | C |
| Number of poles (total) | 1 |
| Degree of protection (IP) | IP20 |
| Flush-mounted installation | false |
| Rated insulation voltage Ui | 440 V |
| Additional equipment possible | true |
| Width in number of modular spacings | 1 |
| Concurrently switching N-neutral | false |
| Ambient temperature during operating | -25 °C |
| Rated short-circuit breaking capacity Icn EN 60898 at 230 V | 10 kA |
| Rated short-circuit breaking capacity Icn EN 60898 at 400 V | 10 kA |
| Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V | 15 kA |
| Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V | 15 kA |
