1716790 - PT 1,5/ 4-PH-3,5 BU BDWH:-V - PCB connector

1716790 - PT 1,5/ 4-PH-3,5 BU BDWH:-V - PCB connector

by Phoenix Contact
$92.64 - $92.64
$92.64
$92.64 - $92.64
$92.64

PCB connector, nominal cross section: 1.5 mm², color: blue, nominal current: 8 A, rated voltage (III/2): 200 V, contact surface: Tin, type of contact: Female connector, number of potentials: 4, number of rows: 1, number of positions: 4, number of connections: 4, product range: PT 1,5/..-PH, pitch: 3.5 mm, connection method: Screw connection with wire protector, conductor/PCB connection direction: 0 °, plug-in system: COMBICON PST 1,0, locking: without, mounting: without, type of packaging: packed in cardboard



Specifications
Item Value
Country of Origin China
Color Blue
Nominal Current 8 A
Contact Surface Tin
Type Of Contact Female connector
Number Of Potentials 4
Number Of Rows 1
Number Of Positions 4
Product Range PT 1
Pitch 3.5 mm
Connection Method Screw connection with wire protector
Locking Without
Mounting Without
Type Of Packaging packed in cardboard
