1767410 - SMSTBA 2,5/ 6-G-5,08 - PCB header

1767410 - SMSTBA 2,5/ 6-G-5,08 - PCB header

by Phoenix Contact
$68.92 - $68.92
$68.92
$68.92 - $68.92
$68.92

PCB headers, nominal cross section: 2.5 mm², color: green, nominal current: 12 A, rated voltage (III/2): 320 V, contact surface: Tin, type of contact: Male connector, number of potentials: 6, number of rows: 1, number of positions: 6, number of connections: 6, product range: SMSTBA 2,5/..-G, pitch: 5.08 mm, mounting: Wave soldering, pin layout: Linear pinning, solder pin [P]: 3.5 mm, number of solder pins per potential: 1, plug-in system: COMBICON MSTB 2,5, Pin connector pattern alignment: Standard, locking: without, mounting: without, type of packaging: packed in cardboard



Specifications
Item Value
Country of Origin Germany
Color Green
Nominal Current 12 A
Contact Surface Tin
Type Of Contact Male connector
Number Of Potentials 6
Number Of Rows 1
Number Of Positions 6
Product Range SMSTBA 2
Pitch 5.08 mm
Mounting Wave Soldering
Pin Layout Linear pinning
Locking Without
Type Of Packaging packed in cardboard
