1005355 - SMKDSP 1,5/ 2-5,08 BD:1-2 - PCB terminal block

1005355 - SMKDSP 1,5/ 2-5,08 BD:1-2 - PCB terminal block

by Phoenix Contact
$234.67 - $234.67
$234.67
$234.67 - $234.67
$234.67

PCB headers, nominal cross section: 1.5 mm², color: green, nominal current: 18 A, rated voltage (III/2): 400 V, contact surface: Tin, number of potentials: 2, number of rows: 1, number of positions: 2, number of connections: 2, product range: SMKDSP 1,5, pitch: 5.08 mm, connection method: Screw connection with tension sleeve, mounting: Wave soldering, conductor/PCB connection direction: 55 °, pin layout: Linear pinning, solder pin [P]: 3.5 mm, number of solder pins per potential: 1, type of packaging: packed in cardboard



Specifications
Item Value
Country of Origin Germany
Color Green
Nominal Current 18 A
Contact Surface Tin
Number Of Potentials 2
Number Of Rows 1
Number Of Positions 2
Product Range SMKDSP 1
Pitch 5.08 mm
Connection Method Screw connection with tension sleeve
Mounting Wave Soldering
Pin Layout Linear pinning
Type Of Packaging packed in cardboard
