1SCA022627R6860 - OFAF3H425 HRC FUSE LINK
by ABB
Original price
$49.02
-
Original price
$49.02
Original price
$49.02
$49.02
-
$49.02
Current price
$49.02
OFAF3H425 HRC Fuse Link Size NH3, gG
Item | Value |
---|---|
Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
Environmental Information | 1SCC317009D0201 |
REACH Declaration | 1SCC011021D0201 |
RoHS Information | 1SCC011020D0201 |
Item | Value |
---|---|
Minimum Order Quantity | 1 piece |
Customs Tariff Number | 85361090 |
Country of Origin | Hungary (HU) |
Item | Value |
---|---|
Product Net Width | 70 mm |
Product Net Height | 150 mm |
Product Net Depth / Length | 84 mm |
Product Net Weight | 1 kg |
Item | Value |
---|---|
Power Loss | 34.0 W |
Fuse Size | NH3 |
Fuse System | DIN |
Standards | IEC 60269 |
Fuse Type | gG |
Rated Current (In) | 425 A |
Rated Voltage (Ur) | 500 V |
Item | Value |
---|---|
RoHS Status | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
Environmental Information | 1SCC317009D0201 |
Item | Value |
---|---|
Object Classification Code | F |
ETIM 9 | EC000055 - Knife blade fuse |
eClass | V11.1 : 27142005 |
WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
E-Number (Finland) | 3112342 |
