3SE5122-3QV10 - INTERLOCK SW, TOP&SIDE ENTRY, 1NO+2NC, 2LED
by Siemens
Original price
$105.42
-
Original price
$105.42
Original price
$105.42
$105.42
-
$105.42
Current price
$105.42
Safety position switch with separate actuator Metal enclosure, 56 mm Device connection 3x (M20x 1.5) Slow-action contacts 1 NO/2 NC with 2 LEDs, 230 V AC yellow/green 5 directions of approaches The matching separate actuator 3SE5000-0AV0. must be ordered
Item | Value |
---|---|
Country of Origin | DE |
Width sensor | 56 mm |
Forced opening | true |
Length of sensor | 110 mm |
Material housing | Metal |
Type of interface | None |
Height of sensor | 37.8 mm |
Coating housing | Lacquered |
With status indication | true |
Degree of protection (NEMA) | 12 |
Construction type housing | Cuboid |
Suitable for safety functions | true |
Degree of protection (IP) | IP66/IP67 |
Number of safety auxiliary contacts | 2 |
Explosion safety category for gas | None |
Explosion safety category for dust | None |
Number of contacts as change-over contact | 0 |
Type of switching contact | Slow-action switch |
Number of contacts as normally open contact | 1 |
Rated operation current Ie at AC-15, 230 V | 4 A |
Ambient temperature during operating | -25 °C |
Number of contacts as normally closed contact | 2 |
Type of interface for safety communication | None |
Type of electric connection | Cable entry metrical |
