1005366 - IC 2,5/ 5-G-5,08 BD:1-5 - PCB header

1005366 - IC 2,5/ 5-G-5,08 BD:1-5 - PCB header

by Phoenix Contact
$158.75 - $158.75
$158.75
$158.75 - $158.75
$158.75

PCB headers, nominal cross section: 2.5 mm², color: green, nominal current: 12 A, rated voltage (III/2): 320 V, contact surface: Tin, type of contact: Female connector, number of potentials: 5, number of rows: 1, number of positions: 5, number of connections: 5, product range: IC 2,5/..-G, pitch: 5.08 mm, mounting: Wave soldering, pin layout: Linear pinning, solder pin [P]: 3.5 mm, number of solder pins per potential: 2, plug-in system: COMBICON MSTB 2,5, Pin connector pattern alignment: Standard, locking: without, mounting: without, type of packaging: packed in cardboard



Specifications
Item Value
Country of Origin Germany
Color Green
Nominal Current 12 A
Contact Surface Tin
Type Of Contact Female connector
Number Of Potentials 5
Number Of Rows 1
Number Of Positions 5
Product Range IC 2
Pitch 5.08 mm
Mounting Wave Soldering
Pin Layout Linear pinning
Locking Without
Type Of Packaging packed in cardboard
