LV433212 - Circuit breaker, ComPact NSX100HB1, 75kA/690VAC, TMD trip unit 50A, 3 poles 3d

LV433212 - Circuit breaker, ComPact NSX100HB1, 75kA/690VAC, TMD trip unit 50A, 3 poles 3d

by Schneider Electric
$599.63 - $599.63
$599.63
$599.63 - $599.63
$599.63

This Compact NSX100HB1 is a complete 3P 3d fixed circuit breaker designed to optimize space and breaking capacity. It is an optimal choice for all standard and specific applications. The breaking capacity (Icu) is 85kA rms at 500VAC 50/60Hz and 75kA rms at 690VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz. This product embeds a 50A rating thermal-magnetic trip unit (TMD). TMD trip unit provides an adjustable thermal overload protection and a fixed magnetic protection. This 3 poles version (105mm x 161mm x 86mm) comes with a variety of optional functions and accessories. It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications. Compact NSX100HB1 is part of Schneider Electric EcoStruxure Power architecture.
