1083352 - SPTAF 1/ 4-3,5-IL BD:SB1-SC2 - PCB terminal block

1083352 - SPTAF 1/ 4-3,5-IL BD:SB1-SC2 - PCB terminal block

by Phoenix Contact
$171.62 - $171.62
$171.62
$171.62 - $171.62
$171.62

PCB terminal block, nominal current: 16 A, rated voltage (III/2): 160 V, nominal cross section: 1.5 mm², number of rows: 1, number of positions per row: 4, product range: SPTAF 1/..-IL, pitch: 3.5 mm, connection method: Push-in spring connection, mounting: Wave soldering, conductor/PCB connection direction: 45 °, color: green, Pin layout: Linear double pinning, Solder pin [P]: 2.6 mm, number of solder pins per potential: 2, type of packaging: packed in cardboard



Specifications
Item Value
Country of Origin Poland
Nominal Current 16 A
Number Of Rows 1
Product Range SPTAF 1/..-IL
Pitch 3.5 mm
Connection Method Push-in spring connection
Mounting Wave Soldering
Color Green
Pin Layout Linear double pinning
Type Of Packaging packed in cardboard
