3VA2450-0MN32-0AA0 - BRKR 3VA24 3P 500A 200KA MCP LSI NUT
by Siemens
Original price
$1,959.99
-
Original price
$1,959.99
Original price
$1,959.99
$1,959.99
-
$1,959.99
Current price
$1,959.99
SIEMENS LOW VOLTAGE 3VA IEC MOTOR CIRCUIT PROTECTOR WITH ELECTRONIC TRIP UNIT. 3VA24 FRAME WITH EXTREMELY HIGH (CLASS E) BREAKING CAPACITY. 500A 3-POLE Icu: (85KAIC AT 690V) (200KAIC AT 415V). ETU350M TRIP UNIT LSI. SPECIAL FEATURES: CONNECTION WITH LUG TERMINAL / NUT KEEPER. DIMENSIONS (W x H x D) IN: 5.4 x 9.8 x 5.4.
Item | Value |
---|---|
Country of Origin | CZ |
Number of poles | 3 |
Rated voltage | 690 V |
Motor drive optional | true |
Motor drive integrated | false |
Degree of protection (IP) | IP40 |
Rated permanent current Iu | 500 A |
With switched-off indicator | false |
Type of control element | Rocker lever |
Overload release current setting | 200 A |
Integrated earth fault protection | false |
Complete device with protection unit | true |
With integrated under voltage release | false |
DIN rail (top hat rail) mounting optional | true |
Suitable for DIN rail (top hat rail) mounting | true |
Number of auxiliary contacts as change-over contact | 0 |
Adjustment range undelayed short-circuit release | 1500 A |
Number of auxiliary contacts as normally open contact | 0 |
Number of auxiliary contacts as normally closed contact | 0 |
Position of connection for main current circuit | Front side |
Device construction | Built-in device fixed built-in technique |
Type of electrical connection of main circuit | Screw connection |
Adjustment range short-term delayed short-circuit release | 1500 A |
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz | 200 kA |
