3VA1125-6EF42-0AA0 - BRKR 3VA11 4P 25A 70KA ATAM NUT
by Siemens
Original price
$268.99
-
Original price
$268.99
Original price
$268.99
$268.99
-
$268.99
Current price
$268.99
SIEMENS LOW VOLTAGE 3VA IEC MOLDED CASE CIRCUIT BREAKER WITH THERMAL - MAGNETIC TRIP UNIT. 3VA11 FRAME WITH HIGH (CLASS H) BREAKING CAPACITY. 25A 4-POLE Icu: (10KAIC AT 690V) (70KAIC AT 415V). TM240 TRIP UNIT WITH ADJUSTABLE Ir ADJUSTABLE Ii. SPECIAL FEATURES: CONNECTION WITH LUG TERMINAL / NUT KEEPER. DIMENSIONS (W x H x D) IN: 4 x 5.1 x 3.5.
Item | Value |
---|---|
Country of Origin | CZ |
Number of poles | 4 |
Rated voltage | 690 V |
Motor drive optional | true |
Motor drive integrated | false |
Degree of protection (IP) | IP40 |
Rated permanent current Iu | 25 A |
With switched-off indicator | false |
Overload release current setting | 18 A |
Type of control element | Rocker lever |
Integrated earth fault protection | false |
Complete device with protection unit | true |
With integrated under voltage release | false |
DIN rail (top hat rail) mounting optional | false |
Suitable for DIN rail (top hat rail) mounting | false |
Adjustment range undelayed short-circuit release | 160 A |
Number of auxiliary contacts as change-over contact | 0 |
Number of auxiliary contacts as normally open contact | 0 |
Number of auxiliary contacts as normally closed contact | 0 |
Position of connection for main current circuit | Front side |
Device construction | Built-in device fixed built-in technique |
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz | 70 kA |
Type of electrical connection of main circuit | Screw connection |
