1SDA067416R1 - XT1N 160 TMD 100-1000 3p F F
by ABB
Original price
$147.69
-
Original price
$147.69
Original price
$147.69
$147.69
-
$147.69
Current price
$147.69
C.BREAKER TMAX XT1N 160 FIXED THREE-POLE WITH FRONT TERMINALS AND THERMOMAGNETIC RELEASE TMD R 100-1000 A
| Item | Value |
|---|---|
| ABB EcoSolutions | Yes |
| Item | Value |
|---|---|
| Circular Design Principles Recyclability Rate | Design for Closing Resource Loops - Standard EN45555 - 60.9 % |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| End of Life Instructions | 9AKK108468A2347 |
| Group Waste to Landfill Target | UL 2799 Zero Waste To Landfill Validation available |
| Toxic Substances Control Act - TSCA | 9AKK108467A8326 |
| Item | Value |
|---|---|
| Environmental Product Declaration - EPD | 9AKK108468A1890 |
| Item | Value |
|---|---|
| Environmental Information | 9AKK107991A8215 9AKK108467A6707 |
| REACH Declaration | 9AKK108466A1425 |
| RoHS Information | 9AKK108466A1424 |
| RoHS Status | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| SCIP | 9dc23701-0389-4d5d-9536-ba4ecc672f9f Italy (IT) |
| Simplified SCIP | 8ebd8f62-f8d3-47fd-bae4-333e0a218076 Greece (GR)db9cca29-2669-426f-bf76-0e2f3f91228f Portugal (PT)01cd358c-7878-4350-a8cb-ad98bcdf704c Bulgaria (BG)b0a036f2-b8f0-4f7f-aefc-8d094fa47899 Sweden (SE)996ed7e4-edc7-4d81-acaa-2cb3aad20176 Poland (PL)8fd3fa87-f754-4249-8c2f-b59e41939151 France (FR)c53d77de-041e-4093-a986-0c6cc61f57c5 Sweden (SE)84ac0468-5c88-4c5d-8651-f235b69841f9 Norway (NO)fbb53485-dd85-4069-8b43-658e7c5756b5 Finland (FI)d200e345-117c-45cc-aa41-8ed4a9afed60 Netherlands (NL)1a85d563-57df-4b20-b426-89ccb3c219e0 Germany (DE)e9fc3286-418a-43e6-a8da-5755bebb9679 Denmark (DK)b375cf2b-78f3-4e1e-ae01-a1a61a24b8a8 Germany (DE)d6dca289-557a-48dd-b4aa-fd4b82c36b75 Croatia (HR)83b9a438-3162-4bc0-be90-1012a3e4b3fc Poland (PL)4f0681cb-c9f4-4a2f-abaf-3d07ac967890 Germany (DE)3b489665-c6a7-4f01-ac7f-d84483cd1553 France (FR)e6c6fa22-a8fe-4514-a81d-fcf5be2a7031 Netherlands (NL)c4a7c5cf-16cb-45a7-8b0f-07ab801af36a Spain (ES)83b9a438-3162-4bc0-be90-1012a3e4b3fc Poland (PL)84ac0468-5c88-4c5d-8651-f235b69841f9 Norway (NO)fbb53485-dd85-4069-8b43-658e7c5756b5 Finland (FI)b0a036f2-b8f0-4f7f-aefc-8d094fa47899 Sweden (SE)2bcd0110-606e-4b4a-96e7-796264c5d0b9 Netherlands (NL)996ed7e4-edc7-4d81-acaa-2cb3aad20176 Poland (PL)8fd3fa87-f754-4249-8c2f-b59e41939151 France (FR)c53d77de-041e-4093-a986-0c6cc61f57c5 Sweden (SE)8b19cf35-ed11-4fe7-8969-08b832056cec Germany (DE)3acf60b8-4063-465a-b3fd-a4c165e3f530 Czech Republic (CZ)5dc72b3c-ae87-4b2b-b761-495b6eb5d7eb Poland (PL)cb2acb5b-5523-4886-9a78-19a9c1e14bee Netherlands (NL)1216d8d6-e907-4c14-bafd-557686032dbe Netherlands (NL)87f2c02c-07fc-4c8f-9140-875e6fa9b620 Estonia (EE)8ebd8f62-f8d3-47fd-bae4-333e0a218076 Greece (GR)db9cca29-2669-426f-bf76-0e2f3f91228f Portugal (PT)8b19cf35-ed11-4fe7-8969-08b832056cec Germany (DE)4f0681cb-c9f4-4a2f-abaf-3d07ac967890 Germany (DE)3b489665-c6a7-4f01-ac7f-d84483cd1553 France (FR)e6c6fa22-a8fe-4514-a81d-fcf5be2a7031 Netherlands (NL)c4a7c5cf-16cb-45a7-8b0f-07ab801af36a Spain (ES)2bcd0110-606e-4b4a-96e7-796264c5d0b9 Netherlands (NL)01cd358c-7878-4350-a8cb-ad98bcdf704c Bulgaria (BG)d200e345-117c-45cc-aa41-8ed4a9afed60 Netherlands (NL)1a85d563-57df-4b20-b426-89ccb3c219e0 Germany (DE)e9fc3286-418a-43e6-a8da-5755bebb9679 Denmark (DK)b375cf2b-78f3-4e1e-ae01-a1a61a24b8a8 Germany (DE)d6dca289-557a-48dd-b4aa-fd4b82c36b75 Croatia (HR)3acf60b8-4063-465a-b3fd-a4c165e3f530 Czech Republic (CZ)5dc72b3c-ae87-4b2b-b761-495b6eb5d7eb Poland (PL)cb2acb5b-5523-4886-9a78-19a9c1e14bee Netherlands (NL)1216d8d6-e907-4c14-bafd-557686032dbe Netherlands (NL)87f2c02c-07fc-4c8f-9140-875e6fa9b620 Estonia (EE) |
| Item | Value |
|---|---|
| E-Number (Finland) | 3640527 |
| E-Number (Sweden) | 3182429 |
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85362090 |
| Item | Value |
|---|---|
| Product Net Width | 76.2 mm |
| Product Net Height | 130 mm |
| Product Net Depth / Length | 70 mm |
| Product Net Weight | 1.1 kg |
| Item | Value |
|---|---|
| Circuit Breaker Type to be Associated | Power Distribution |
| Connecting Capacity Main Circuit | Busbar 45.5 ... 80 mm² |
| Current Type | AC/DC |
| Electrical Durability | 120 cycles per hour8000 cycle |
| Mechanical Durability | 240 cycles per hour25000 cycle |
| Number of Poles | 3 |
| Opening Time | CB with SOR 15 msCB with UVR 15 ms |
| Order Multiple | 1 piece |
| Power Loss | at Rated Operating Conditions per Pole 7 W |
| Product Main Type | SACE Tmax XT |
| Product Name | Moulded Case Circuit Breaker |
| Product Type | Automatic Circuit Breaker |
| Rated Current (In) | 100 A |
| Rated Frequency (f) | 50 / 60 Hz |
| Rated Voltage (Ur) | 690 V |
| Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Rated Instantaneous Short-Circuit Current Setting (Ii) | 1000 A |
| Rated Insulation Voltage (Ui) | 800 V |
| Rated Operational Voltage | 690 V AC500 V DC |
| Rated Service Short-Circuit Breaking Capacity (Ics) | (220 V AC) 50 kA(230 V AC) 50 kA(240 V AC) 50 kA(380 V AC) 36 kA(415 V AC) 36 kA(440 V AC) 18 kA(500 V AC) 15 kA(525 V AC) 11 kA(690 V AC) 5 kA(250 V DC) 2 Poles in Series 36 kA(500 V DC) 3 Poles in Series 36 kA |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu) | (220 V AC) 65 kA(230 V AC) 65 kA(240 V AC) 65 kA(380 V AC) 36 kA(415 V AC) 36 kA(440 V AC) 36 kA(500 V AC) 30 kA(525 V AC) 22 kA(690 V AC) 6 kA(250 V DC) 2 Poles in Series 36 kA(500 V DC) 3 Poles in Series 36 kA |
| Rated Uninterrupted Current (Iu) | 160 A |
| Recommended Screw Driver | Main Circuit M6 |
| Release | TMD |
| Release Type | TM |
| RoHS Date | NA |
| Setting Range | 70...100 A |
| Short-Circuit Performance Level | N |
| Standards | IEC |
| Sub-type | XT1 |
| Terminal Connection Type | Front |
| Terminal Type | Bolt |
| Tightening Torque | 6 N·m |
| Version | F |
| CAD Dimensional Drawing | 1SDH001295R0008 |
| Item | Value |
|---|---|
| Object Classification Code | Q |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| eClass | V11.1 : 27370409 |
