8WH6020-0CG07 - DO-TERM. 4MM2, 6, 2MM, PE
by Siemens
Original price
$9.96
-
Original price
$9.96
Original price
$9.96
$9.96
-
$9.96
Current price
$9.96
PE-TWO TIER TERMINAL BLOCK 4 MM2, 6,2 MM WIDTH GREY
| Item | Value |
|---|---|
| Colour | Other |
| Country of Origin | DE |
| Width | 6.15 mm |
| Depth | 45.86 mm |
| Height | 83.68 mm |
| Number of levels | 2 |
| Closing plate required | true |
| PEN function possible | false |
| Material insulation body | Other |
| Operation temperature | 105 °C |
| Number of clamp positions per level | 4 |
| Type of electrical connection 1 | Other |
| Type of electrical connection 2 | Other |
| Mounting method | DIN rail (top hat rail) 35 mm |
| Inflammability class of insulation material acc. with UL94 | V0 |
| Connectable conductor cross section solid-core | 0.199999999 mm² |
| Connectable conductor cross section multi-wired | 0.199999999 mm² |
| Connectable conductor cross section fine-strand with cable end sleeve | 0.25 mm² |
