3VA5160-4ED11-0AA0 - BRKR 3VA51 1P 60A 25KA FTFM

3VA5160-4ED11-0AA0 - BRKR 3VA51 1P 60A 25KA FTFM

by Siemens
$90.86 - $90.86
$90.86
$90.86 - $90.86
$90.86

SIEMENS LOW VOLTAGE 3VA UL MOLDED CASE CIRCUIT BREAKER WITH THERMAL - MAGNETIC TRIP UNIT. 3VA51 FRAME WITH STANDARD (CLASS S) BREAKING CAPACITY. 60A 1-POLE (14KAIC AT 347V) (25KAIC AT 277V). TM210 TRIP UNIT WITH FIXED Ir FIXED Ii. SPECIAL FEATURES: WITHOUT LUGS. DIMENSIONS (W x H x D) IN: 1 x 5.5 x 3.7.



Specifications
Item Value
Country of Origin CZ
Number of poles 1
Rated voltage 415 V
Motor drive optional false
Motor drive integrated false
Degree of protection (IP) IP40
Rated permanent current Iu 60 A
With switched-off indicator false
Overload release current setting 42 A
Type of control element Rocker lever
Integrated earth fault protection false
Complete device with protection unit true
With integrated under voltage release false
DIN rail (top hat rail) mounting optional true
Suitable for DIN rail (top hat rail) mounting true
Type of electrical connection of main circuit Other
Adjustment range undelayed short-circuit release 600 A
Number of auxiliary contacts as change-over contact 0
Position of connection for main current circuit Other
Number of auxiliary contacts as normally open contact 0
Number of auxiliary contacts as normally closed contact 0
Device construction Built-in device fixed built-in technique
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz 5 kA
