5SJ4125-6HG40 - MCB 5SJ4 1P 240V 25A SAME PH 14K B-TRIP
by Siemens
Original price
$32.24
-
Original price
$32.24
Original price
$32.24
$32.24
-
$32.24
Current price
$32.24
MCB UL489 1-P 25A B-TRIP SAME PHASE ONLY MINIATURE CIRCUIT-BREAKER 240 V 15 KA, 1-POLE, B, 25 A, D=70 MM TO UL 489, SAME POLARITY
| Item | Value |
|---|---|
| Rated current | 25 A |
| Country of Origin | DE |
| Pollution degree | 3 |
| Rated voltage | 400 V |
| Voltage type | AC/DC |
| Built-in depth | 70 mm |
| Explosion-proof | false |
| Over voltage category | 3 |
| Release characteristic | B |
| Number of poles (total) | 1 |
| Degree of protection (IP) | IP20 |
| Flush-mounted installation | false |
| Rated insulation voltage Ui | 440 V |
| Additional equipment possible | true |
| Width in number of modular spacings | 1 |
| Concurrently switching N-neutral | false |
| Ambient temperature during operating | -25 °C |
| Rated short-circuit breaking capacity Icn EN 60898 at 230 V | 10 kA |
| Rated short-circuit breaking capacity Icn EN 60898 at 400 V | 10 kA |
| Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V | 15 kA |
| Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V | 15 kA |
