1033120 - PTSA 1,5/ 5-3,5-Z MC OG/YE/BK - PCB terminal block
Original price
$224.16
-
Original price
$224.16
Original price
$224.16
$224.16
-
$224.16
Current price
$224.16
PCB terminal block, nominal current: 8 A, rated voltage (III/2): 400 V, nominal cross section: 1.5 mm², number of potentials: 5, number of rows: 1, number of positions per row: 5, product range: PTSA 1,5, pitch: 3.5 mm, connection method: Push-in spring connection, mounting: Wave soldering, conductor/PCB connection direction: 45 °, color: multicolored, Pin layout: Zigzag pinning M, Solder pin [P]: 3.5 mm, number of solder pins per potential: 1, type of packaging: packed in cardboard
| Item | Value |
|---|---|
| Country of Origin | China |
| Nominal Current | 8 A |
| Number Of Potentials | 5 |
| Number Of Rows | 1 |
| Product Range | PTSA 1 |
| Pitch | 3.5 mm |
| Connection Method | Push-in spring connection |
| Mounting | Wave Soldering |
| Color | Multicolored |
| Pin Layout | Zigzag pinning M |
| Type Of Packaging | packed in cardboard |
