3RS1100-2CD20 - TMP MON REL, J T/C, 0-200, 24VAC/DC, CL
by Siemens
Original price
$184.76
-
Original price
$184.76
Original price
$184.76
$184.76
-
$184.76
Current price
$184.76
Temperature Monitoring Relay SIMIREL Conversion Type = Analog Number of Sensors = 1 Sensor Type = Type J Function = Over Temperature Measuring Range = 0..+200 Control Voltage = 24VUC Spring
| Item | Value |
|---|---|
| Depth | 91 mm |
| Country of Origin | DE |
| Height | 103 mm |
| Width | 22.5 mm |
| With detachable clamps | true |
| External reset possible | false |
| Number of measuring circuits | 1 |
| Voltage type for actuating | AC/DC |
| Error registration possible | false |
| Rated control supply voltage Us at DC | 24 V |
| Number of contacts as change-over contact | 0 |
| Number of contacts as normally open contact | 1 |
| Rated control supply voltage Us at AC 50HZ | 24 V |
| Rated control supply voltage Us at AC 60HZ | 24 V |
| Number of contacts as normally closed contact | 1 |
| Type of electric connection | Spring clamp connection |
