3RS1142-1GW80 - TEMPERATURE MONITOR RELAY

3RS1142-1GW80 - TEMPERATURE MONITOR RELAY

by Siemens
$391.25 - $391.25
$391.25
$391.25 - $391.25
$391.25

2 x 1 co + 1 no, width 45 mm, 24 v to 240 V AC/DC, (sensor-dependent), -99 degrees c to 1800 degrees c 2 thresholds, digital, thermocouple j,k,t,e,n,s,r,b, in accordance with din 3440, temperature sensor/limiter



Specifications
Item Value
Country of Origin DE
Depth 91 mm
Width 45 mm
Height 106 mm
With detachable clamps true
External reset possible true
Number of measuring circuits 1
Error registration possible true
Voltage type for actuating AC/DC
Rated control supply voltage Us at DC 24 V
Number of contacts as change-over contact 2
Type of electric connection Screw connection
Number of contacts as normally open contact 1
Rated control supply voltage Us at AC 50HZ 24 V
Rated control supply voltage Us at AC 60HZ 24 V
Number of contacts as normally closed contact 0
