1096794 - PT 1,5/ 4-PH-5,0 OG - PCB connector (Qty. 250)
Original price
$286.87
-
Original price
$286.87
Original price
$286.87
$286.87
-
$286.87
Current price
$286.87
PCB connector, nominal cross section: 1.5 mm², color: orange, nominal current: 10 A, rated voltage (III/2): 400 V, contact surface: Tin, type of contact: Female connector, number of rows: 1, number of positions: 4, product range: PT 1,5/..-PH, pitch: 5 mm, connection method: Screw connection with tension sleeve, screw head form: H1L Philipps recess with slotted Torx, conductor/PCB connection direction: 0 °, plug-in system: COMBICON PST 1,3, locking: without, mounting: without, type of packaging: packed in cardboard
Item | Value |
---|---|
Country of Origin | China |
Color | Orange |
Nominal Current | 10 A |
Contact Surface | Tin |
Type Of Contact | Female connector |
Number Of Rows | 1 |
Number Of Positions | 4 |
Product Range | PT 1 |
Pitch | 5 mm |
Connection Method | Screw connection with tension sleeve |
Screw Head Form | H1L Philipps recess with slotted Torx |
Locking | Without |
Mounting | Without |
Type Of Packaging | packed in cardboard |
