1008663 - MC 1,5/ 2-ST-3,81 OG - PCB connector (Qty. 250)

1008663 - MC 1,5/ 2-ST-3,81 OG - PCB connector (Qty. 250)

by Phoenix Contact
$289.45 - $289.45
$289.45
$289.45 - $289.45
$289.45

PCB connector, nominal cross section: 1.5 mm², color: orange, nominal current: 8 A, rated voltage (III/2): 160 V, contact surface: Tin, type of contact: Female connector, number of rows: 1, number of positions: 2, product range: MC 1,5/..-ST, pitch: 3.81 mm, connection method: Screw connection with tension sleeve, screw head form: L Slotted, conductor/PCB connection direction: 0 °, number of solder pins per potential: 1, plug-in system: COMBICON MC 1,5, locking: without, mounting: without, type of packaging: packed in cardboard



Specifications
Item Value
Country of Origin Germany
Color Orange
Nominal Current 8 A
Contact Surface Tin
Type Of Contact Female connector
Number Of Rows 1
Number Of Positions 2
Product Range MC 1
Pitch 3.81 mm
Connection Method Screw connection with tension sleeve
Screw Head Form L Slotted
Locking Without
Mounting Without
Type Of Packaging packed in cardboard
