1015763 - PLA 5/ 3-7,5-ZF BU - PCB terminal block (Qty. 25)

1015763 - PLA 5/ 3-7,5-ZF BU - PCB terminal block (Qty. 25)

by Phoenix Contact
$107.28 - $107.28
$107.28
$107.28 - $107.28
$107.28

PCB terminal block, nominal current: 41 A, rated voltage (III/2): 1000 V, nominal cross section: 6 mm², number of rows: 1, number of positions per row: 3, product range: PLA 5/, pitch: 7.5 mm, connection method: Push-lock spring connection, mounting: Wave soldering, conductor/PCB connection direction: 30 °, color: gray, Pin layout: Zigzag pinning W, Solder pin [P]: 3.6 mm, number of solder pins per potential: 1, type of packaging: packed in cardboard



Specifications
Item Value
Country of Origin Slovakia
Nominal Current 41 A
Number Of Rows 1
Product Range PLA 5/
Pitch 7.5 mm
Connection Method Push-lock spring connection
Mounting Wave Soldering
Color Gray
Pin Layout Zigzag pinning W
Type Of Packaging packed in cardboard
