1729186 - MKDSN 1,5/ 8-5,08 - PCB terminal block (Qty. 60)

1729186 - MKDSN 1,5/ 8-5,08 - PCB terminal block (Qty. 60)

by Phoenix Contact
$129.85 - $129.85
$129.85
$129.85 - $129.85
$129.85

PCB terminal block, nominal current: 13.5 A, rated voltage (III/2): 400 V, nominal cross section: 1.5 mm², number of potentials: 8, number of rows: 1, number of positions per row: 8, product range: MKDSN 1,5, pitch: 5.08 mm, connection method: Screw connection with tension sleeve, screw head form: L Slotted, mounting: Wave soldering, conductor/PCB connection direction: 0 °, color: green, Pin layout: Linear pinning, Solder pin [P]: 3.5 mm, number of solder pins per potential: 1, type of packaging: packed in cardboard



Specifications
Item Value
Country of Origin Germany
Nominal Current 13.5 A
Number Of Potentials 8
Number Of Rows 1
Product Range MKDSN 1
Pitch 5.08 mm
Connection Method Screw connection with tension sleeve
Screw Head Form L Slotted
Mounting Wave Soldering
Color Green
Pin Layout Linear pinning
Type Of Packaging packed in cardboard
