140G-I3C3-D20-BA - 140G-I3C3-D20-BA - 140G Molded Case Circuit Breakers & Molded Case Switch

140G-I3C3-D20-BA - 140G-I3C3-D20-BA - 140G Molded Case Circuit Breakers & Molded Case Switch

by Rockwell Automation
$1,279.03 - $1,279.03
$1,279.03
$1,279.03 - $1,279.03
$1,279.03

140G - Molded Case Circuit Breaker, I frame, 35 kA, T/M - Thermal Magnetic, 3 Poles, Rated Current 200 A, 2 NO/NC AUX + Alarm, 250V



Specifications
Item Value
Bulletin Number 140G - Molded Case Circuit Breaker
Frame/Rating I Frame (225 A)
Interrupting Rating, 50/60 Hz, 240V (kA) 65
Interrupting Rating, 50/60 Hz, 480V (kA) 35
Interrupting Rating, 50/60 Hz, 600V (kA) 10
Breaking Capacity, 50/60 Hz, 220V (kA) 85
Breaking Capacity, 50/60 Hz, 415V (kA) 50
Breaking Capacity, 50/60 Hz, 440V (kA) 40

Circuit Breaker Data
Item Value
Device Type 140G - Molded Case Circuit Breaker
Number of Poles 3 Poles
Frame Size I frame
Rated Current(A) 200 A
Protection T/M - Thermal Magnetic

Manufacturing
Item Value
Assembly Factory Assembled

Internal Accessories
Item Value
Auxiliary and Alarm Contacts 2 NO/NC AUX + Alarm, 250V

2-Dimensional Drawing (PDF)
Link to Literature Library for Selectivity Guide
2-Dimensional Drawing (DWG/DXF)
Link to Literature Library for Installation Instructions
Link to Literature Library for Tech Data
3-Dimensional STEP model (STP)
