1017521 - TDPT 4/ 2-SP-6,35-ZB - PCB terminal block (Qty. 50)

1017521 - TDPT 4/ 2-SP-6,35-ZB - PCB terminal block (Qty. 50)

by Phoenix Contact
$87.84 - $87.84
$87.84
$87.84 - $87.84
$87.84

PCB terminal block, nominal current: 41 A, rated voltage (III/2): 1000 V, nominal cross section: 4 mm², number of potentials: 2, number of rows: 1, number of positions per row: 2, product range: TDPT 4/..-SP, pitch: 6.35 mm, connection method: Push-in spring connection, mounting: Wave soldering, conductor/PCB connection direction: 0 °, color: green, Pin layout: Zigzag pinning W, Solder pin [P]: 3.5 mm, number of solder pins per potential: 1, type of packaging: packed in cardboard



Specifications
Item Value
Country of Origin China
Nominal Current 41 A
Number Of Potentials 2
Number Of Rows 1
Product Range TDPT 4/..-SP
Pitch 6.35 mm
Connection Method Push-in spring connection
Mounting Wave Soldering
Color Green
Pin Layout Zigzag pinning W
Type Of Packaging packed in cardboard
