1755680 - PT 1,5/12-PH-5,0 - PCB connector (Qty. 50)
Original price
$182.32
-
Original price
$182.32
Original price
$182.32
$182.32
-
$182.32
Current price
$182.32
PCB connector, nominal cross section: 1.5 mm², color: green, nominal current: 10 A, rated voltage (III/2): 400 V, contact surface: Tin, type of contact: Female connector, number of potentials: 12, number of rows: 1, number of positions: 12, number of connections: 12, product range: PT 1,5/..-PH, pitch: 5 mm, connection method: Screw connection with tension sleeve, screw head form: H1L Philipps recess with slotted Torx, conductor/PCB connection direction: 0 °, plug-in system: COMBICON PST 1,3, locking: without, mounting: without, type of packaging: packed in cardboard
| Item | Value |
|---|---|
| Country of Origin | China |
| Color | Green |
| Nominal Current | 10 A |
| Contact Surface | Tin |
| Type Of Contact | Female connector |
| Number Of Potentials | 12 |
| Number Of Rows | 1 |
| Number Of Positions | 12 |
| Product Range | PT 1 |
| Pitch | 5 mm |
| Connection Method | Screw connection with tension sleeve |
| Screw Head Form | H1L Philipps recess with slotted Torx |
| Locking | Without |
| Mounting | Without |
| Type Of Packaging | packed in cardboard |
