BRKR 3VA14 3P 500A 110KA ATFM NUT
by Siemens
Original price
$1,378.65
-
Original price
$1,378.65
Original price
$1,378.65
$1,378.65
-
$1,378.65
Current price
$1,378.65
SIEMENS LOW VOLTAGE 3VA IEC MOLDED CASE CIRCUIT BREAKER WITH THERMAL - MAGNETIC TRIP UNIT. 3VA14 FRAME WITH VERY HIGH (CLASS C) BREAKING CAPACITY. 500A 3-POLE Icu: (6KAIC AT 600V) (110KAIC AT 415V). TM220 TRIP UNIT WITH ADJUSTABLE Ir FIXED Ii. SPECIAL FEATURES: CONNECTION WITH LUG TERMINAL / NUT KEEPER. DIMENSIONS (W x H x D) IN: 5.4 x 9.8 x 5.4.
| Item | Value |
|---|---|
| Pole number | 3 |
| Country of Origin | CZ |
| Protection type IP | IP40 |
| Motor drive optional | true |
| Integrated motor drive | false |
| Design of actuating element | Tilt lever |
| Number of auxiliary contacts as opener | 0 |
| Number of auxiliary contacts as changer | 0 |
| Number of auxiliary contacts as shutter | 0 |
| integrated earth-fault protection present | false |
| Power loss per pole, current-dependent [PlIp] | 40.9 watt |
| Position of the connection for the main circuit | Front connection |
| Greatest value of tuning range short circuit tripper, undelayed | 5000 ampere |
| Lowest value of setting range for short circuit tripper, undelayed | 5000 ampere |
