MLBL-09Y LED block (Qty. 10)

MLBL-09Y LED block (Qty. 10)

by ABB
$104.45 - $104.45
$104.45
$104.45 - $104.45
$104.45

The MLBL-09Y LED block is: Without holder - Yellow - Illuminated - Front mounting - 415 V



Ordering
Item Value
Minimum Order Quantity 10 piece
Customs Tariff Number 85369001

Dimensions
Item Value
Product Net Width 0.01 m
Product Net Height 0.044 m
Product Net Depth / Length 0.042 m
Product Net Weight 0.01 kg

Technical
Item Value
Ambient Air Temperature Operation -25 ... +70 °CStorage -40 ... +85 °C
Color Yellow
Illumination Illuminated
Lamp Type 415 V AC, integrated LED
Mounting Type Front mounting
Degree of Protection Terminals IP20
Rated Frequency (f) 50 / 60 Hz
Rated Operational Voltage 415 V AC
Connecting Capacity Flexible with Ferrule 1 x 0.75...2.5 mm²Flexible with Ferrule 2 x 0.75...2.5 mm²Flexible with Insulated Ferrule 1 x 0.75...2.5 mm²Flexible with Insulated Ferrule 2 x 0.75...2.5 mm²Flexible 1 x 0.75 ... 2.5 mm²Flexible 2 x 0.75 ... 2.5 mm²Solid 1 x 0.75...2.5 mm²Solid 2 x 0.75...2.5 mm²
Connection Type Screw Clamp
Terminal Type Screw Terminals
Tightening Torque 0.9 N·m
Wire Stripping Length 8 mm
Suitable For MCBH-00MCBH5-00MP1MP2MP3MP4MPMT3MPMP3M2SS1M2SS2M2SS3M2SS4M2SS5M2SS6M3SS1M3SS2M3SS3M3SS4M3SS5M3SS6M3SS7M3SS8MPM1
Suitable for Product Class Pilot Devices

Technical UL/CSA
Item Value
Connecting Capacity UL/CSA 1x 18...14 AWG2x 18...14 AWG

Environmental
Item Value
RoHS Status Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
RoHS Date 0635 4
RoHS Information 2CMT2015-005452
WEEE Category 5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B Business To Business

Classifications
Item Value
Object Classification Code E
eClass V11.0 : 27371209
E-Number (Finland) 2315787
E-Number (Sweden) 3705635
